TCP Packet Explained

TCP (Transmission Control Protocol) is a highly reliable host-to-host protocol to support multiple network systems, which is documented in RFC 793. Below I have mentioned the structure of the TCP packet.

tcp packet

TCP Packet contains the following fields:

  • Source Port and Destination Port fields (16 bits each) - Source and Destination port number
  • Sequence Number field (32 bits) - sequence number of the first data byte or data octet
  • Acknowledgment Number field (32 bits)
  • Data Offset field (variable length) - indicates the starting point of data
  • Reserved field (6 bits) - kept for future use and must be zero.
  • Flags field (6 bits - URG, ACK, PSH, RST, SYN, FIN) - signifies different flags
  • Window field (16 bits) - mention window's size of the sender
  • Checksum field (16 bits) - to ensure the integrity
  • Urgent pointer field (16 bits) - point to urgent data type
  • Options field (variable length) - multiple options
  • Data field (variable length)
